商品描述

產地 : 台灣

非大陸品牌

效能700Mbps硬體加速940Mbps~1800Mbps

規格

介面
WAN埠	1x GbE RJ-45
WAN/LAN可切換埠	1x GbE RJ-45
LAN埠	5x GbE RJ-45
USB孔	2x USB 2.0 (可接4G/LTE USB行動網卡、USB磁碟、印表機或USB溫度計)
Wi-Fi 天線	2x 可拆式 Dipole 增益: 5GHz頻段3dBi、2.4GHz頻段2.5dBi (無線機種)
2.4G 無線網路	802.11n 2x2 MIMO 400Mbps (無線機種)
5G 無線網路	802.11ac Wave 2 2x2 MU-MIMO 867Mbps (雙頻無線機種)
效能
NAT最快速度	800 Mbps
啟用硬體加速NAT最快速度	940 Mbps (單WAN) 1.8 Gbps (雙WAN)
同時最多NAT連線數	60,000
同時最多VPN連線數	50
同時最多OpenVPN + SSL VPN連線數	25
Internet Connection
IPv4	PPPoE, DHCP, Static IP, PPTP/L2TP
IPv6	PPP, DHCPv6, Static IPv6, TSPC, AICCU, 6rd, 6in4 Static Tunnel
802.1p/q Multi-VLAN Tagging	有
Multi-VLAN/PVC	有
Wireless WAN	(ac model)
4G/LTE WAN with USB modem	有
Load Balancing	IP-based, Session-based
WAN Active on Demand	Link Failure, Traffic Threshold
Connection Detection	ARP, Ping
WAN Data Budget	有
Dynamic DNS	有
DrayDDNS	有
LAN Management
VLAN	802.1q Tag-based, Port-based
Max. Number of VLAN	16
Number of LAN Subnet	8
DHCP Server	Multiple IP Subnet, Custom DHCP Options, Bind-IP-to-MAC
LAN IP Alias	有
Wired 802.1x Authentication	有
Port Mirroring	有
Local DNS Server	有
Conditional DNS Forwarding	有
Hotspot Web Portal	有
Hotspot Authentication	Click-Through, Social Login, SMS PIN, Voucher PIN, RADIUS, External Portal Server
Networking
Routing	IPv4 Static Routing, IPv6 Static Routing, Inter-VLAN Routing, RIP, BGP
Policy-based Routing	Protocol, IP Address, Port, Domain, Country
High Availability	有
DNS Security (DNSSEC)	有
Multicast	IGMP Proxy, IGMP Snooping & Fast Leave, Bonjour
Local RADIUS server	有
SMB File Sharing	(Requires external storage)
VPN
LAN-to-LAN	有
Teleworker-to-LAN	有
Protocols	PPTP, L2TP, IPsec, L2TP over IPsec, SSL, GRE, IKEv2, IKEv2-EAP, IPsec-XAuth, OpenVPN,Wireguard VPN(v4.4.3)
User Authentication	Local, RADIUS, LDAP, TACACS+, mOTP
IKE Authentication	Pre-Shared Key, X.509
IPsec Authentication	SHA-1, SHA-256
Encryption	MPPE, DES, 3DES, AES
VPN Trunk (Redundancy)	Load Balancing, Failover
Single-Armed VPN	有
NAT-Traversal (NAT-T)	有
DrayTek VPN Matcher	有
Firewall & Content Filtering
NAT	Port Redirection, Open Ports, Port Triggering, DMZ Host, UPnP
ALG (Application Layer Gateway)	SIP, RTSP, FTP, H.323
VPN Pass-Through	PPTP, L2TP, IPsec
IP-based Firewall Policy	有
Content Filtering	Application, URL, DNS Keyword, Web Features, Web Category* (*: subscription required)
DoS Attack Defense	有
Spoofing Defense
Bandwidth Management
IP-based Bandwidth Limit	有
IP-based Session Limit	有
QoS (Quality of Service)	TOS, DSCP, 802.1p, IP Address, Port, Application
VoIP Prioritization	有
Wireless LAN (wireless model)
Number of SSID	4 per radio band
Security Mode	OWE, WEP, WPA, WPA2, Mixed(WPA+WPA2), WPA3
Authentication	Pre-Shared Key, 802.1X
WPS	PIN, PBC
WDS	Repeater (5GHz only)
Access Control	Access List, Client Isolation, Hide SSID, Wi-Fi Scheduling
AirTime Fairness	有
Band Steering	(dual-band model)
MU-MIMO	(5GHz Only) (dual-band model)
WMM	有
Management
Local Service	HTTP, HTTPS, Telnet, SSH v2, FTP, TR-069
Config File Export & Import	有
Config File Compatibility	Vigor2926
Firmware Upgrade	TFTP, HTTP, TR-069
2-Level Administration Privilege	有
Access Control	Access List, Brute Force Protection
Notification Alert	SMS, E-mail
SNMP	v1, v2c, v3
Syslog	有
Managed by VigorACS	有
Central VPN Management	8 VPN
Central AP Management	20 VigorAP
Mesh Network	7 VigorAP
Central Switch Management	10 VigorSwitch
物理特性
電源	DC 12V @ 2A
最大電耗	24 watts (ac機種)
尺寸	241mm x 165mm x 44mm
重量	630g (ac機種)
操作溫度範圍	0 至 45°C
儲存溫度範圍	-25 至 70°C
操作濕度範圍(non-condensing)	10 至 90%
安規認證
