規格
介面 |
|
| LAN埠 | 5x Gigabit Ethernet (1 PoE) |
| USB孔 | 1x USB 2.0 |
| 天線 | 2x 可卸式雙頻天線 增益: 4 dBi for 5GHz, 2 dBi for 2.4GHz |
| 按鈕 | 1x 重設按鈕 1x 無線/WPS 開關 1x 電源開關 |
WLAN |
|
| 2.4GHz標準 | IEEE 802.11b/g/n |
| 5GHz標準 | IEEE 802.11a/n/ac Wave 2 |
| 2.4GHz最高速度 | 300 Mbps |
| 5Hz最高速度 | 867 Mbps |
| 連線設備數量 | 128 (每個頻段64個) |
| 操作模式 | AP, Mesh Root, Mesh Node, Range Exntender |
| Roaming | AP-Assisted Roaming, PMK-Caching, Pre-Authentication, 802.11r |
| Airtime Fairness | 有 |
| Band Steering | 有 |
| MU-MIMO | (5GHz Only) |
| Auto Channel Selection | 有 |
| Max. Number of SSID | 8 (4 per radio band) |
| WDS | (5GHz only) |
| Bandwidth Limit per Station | 有 |
| Client Number Limit | Per radio, Per SSID |
| Connection Time Control | 有 |
| WMM | 有 |
| IGMP Snooping | 有 |
Security |
|
| Security Mode | WPA3, WPA3/WPA2, WPA2, WPA2/WPA, OWE, WPA, WEP, None |
| Authentication | Personal, Enterprise |
| WPS | PIN, PBC |
| Hidden SSIDs | 有 |
| MAC Address Filter | Up to 128 entries |
| Wireless Client Isolation | 有 |
| Mobile Device Management | 有 |
Application |
|
| Built-in RADIUS Server | 有 |
| RADIUS Proxy | PEAP, EAP-TLS |
| DHCP | DHCP Server, DHCP, Client, DHCP Relay Agent |
| Static IP | 有 |
| MAC Clone | 有 |
| 802.1q VLAN | 有 |
| Schedule | Auto-Reboot, Wi-Fi Up/Down, LED On/Off |
Management |
|
| Local Service | HTTP, HTTPS, Telnet |
| Configuration | Stand Alone, TR-069 (VigorACS), Vigor Router APM, VigorAP Mesh Root |
| Tools | Speed Test, AP Discovery, Statistics |
| Syslog | 有 |
| SNMP | v2, v2c, v3 |
| Managed by VigorConnect | 有 |
| Managed by VigorACS | 有 |
| Central AP Management | 20 VigorAP |
物理特性 |
|
| 適用環境 | 室內 |
| 安裝方式 | 壁掛式 / 桌立式 |
| 供電方式 | DC 12V @ 1.4A / 802.3at PoE |
| 最大功耗 | 16 watts |
| 尺寸 | 107mm x 167mm x 45mm |
| 重量 | 330g |
| 操作溫度範圍 | 0 至 45°C |
| 儲存溫度範圍 | -25 至 70°C |
| 操作濕度範圍 | 10 至 90% non-condensing |
| 認證 |     |
| NCC 證號 | CCAF18LP1210T6 |
